Industrial PC Edge Computer Neu-X102-N97 8GB RAM 256GB SSD Windows IoT

Dekstop PC Neu-X102 Intel Celeron N97, 8GB RAM, 256GB SSD, Power Adaptor, Windows 10 IoT

EDGE COMPUTING
Edge Computing atau Komputasi tepian adalah model komputasi terdistribusi yang mendekatkan komputasi dan penyimpanan data ke sumber data. Secara lebih luas, ini mengacu pada desain apa pun yang mendorong komputasi secara fisik lebih dekat ke pengguna, sehingga dapat mengurangi latensi dibandingkan ketika aplikasi berjalan pada pusat data terpusat.

Komputasi Edge, atau komputasi tepian dalam Bahasa Indonesia, adalah sebuah model komputasi terdistribusi yang memproses data sedekat mungkin dengan sumber aslinya, di bagian "tepi" jaringan. Dengan kata lain, pemrosesan data dilakukan secara lokal di perangkat atau server kecil yang berada dekat dengan tempat data tersebut dihasilkan.

Neu-X102 series are powered by Intel®, processor N50, N97 (Alder Lake-N) featuring upgraded computing performance with low power-efficient and integrated a rich set of IOT features.

It supports 2 x HDMI 1.4b display outputs, dual 2.5GbE LAN ports, 4 x USB 3.2 Gen2 ports, 1 x RS232/RS422/RS485 port and a M.2 2242 Key M storage slot that supports PCIe and SATA format.

In addition, the mPCIe slot support LTE and Wi-Fi6/6E module. With the LTE and Wi-Fi communication, provide the wide-area coverage and real-time transmission for gateway applications.

With its slim, compact-size, fanless design and extended durability can furtherly cover a lot of usages like IOT gateway, self-service kiosks, endless aisles, QSRs, drive-thru kiosks, bus stops, digital transit information signs, intelligent Pole/lighting system, information display system, such as PIDS for smart city.

CPU Support
Intel® processor, N97, 12W, up to 3.6GHz

Graphic & Display
Intel® UHD graphics

Main Memory
1 x 260-pin DDR4 SO-DIMM socket, up to 3200MHz with non-ECC, un-buffered memory up to 16GB

I/O Interface-Front
2 x RJ45 with LEDs for 2.5GbE LAN
2 x HDMI 1.4b, resolution 3840 x 2160@30Hz
4 x USB 3.2
1 x Power button with LED
1 x DC-in Jack with lock

I/O Interface-Rear
2 x Antenna hole
1 x COM port (RS232/RS422/RS485)
1 x Storage active LED

Internal I/O
1 x COM port connector (RS232, RI/5V/12V)
1 x Line-out audio connector
2 x 6-pin header for 3 x USB 2.0 ports
1 x 10-pin header for GPIO, 4 x GPI, 4 x GPO

Expansion
1 x mini-PCIe full-size connector with SIM slot (nano) onboard, support Wi-Fi 6/6E & LTE module

Storage
1 x M.2 2242 Key M storage for supporting SATA & PCIe signal

Power Supply
1 x External 12V/5A, 60W power adapter (Included in accessory)
Input: DC+12V DC

Environment
Operating temperature: -5°C to 50°C ambient with 0.7m/s air flow
Humidity: 95% (non-condensing)
Storage temperature: -20°C to 80°C
Shock protection: 50G peak acceleration, 11ms according to IEC60068-2-27
Vibration protection
- Random: 2Grms @ 5~500 Hz, IEC60068-2-64
- Sinusoidal: 2G @ 5~500 Hz, IEC60068-2-6
Mechanical & Dimension
Aluminum and metal chassis with fanless design
203.5mm (W) x 106mm(D) x 40mm (H)

Certification
CE (EN55035 + EN55032)
FCC Class A (EMI part 15B)
LVD (EN62368-1)

Operating System
Win10 64-bit, Win 11
Linux 4.1 above

Package Information
Dimension: 296x276x205mm

Warranty: 1 year
